Needles Lighthouse

Before work could begin on the new tower, a sizeable section of rock was cut away to provide a level base. Tunnels were also excavated within the rock behind the tower to provide rooms for storage. An oil burner, with four concentric wicks, provided the light source atop the new tower; it was set within a large (first-order) fixed catadioptric optic provided by Henry-Lepaute of Paris. By 1884 a further (green) sector had been added and the light made occulting. The tower itself had initially been left as plain granite 'not coated nor coloured', In 1922, a more powerful incandescent paraffin vapour burner was installed, which increased the intensity of the light from 35,000 to 500,000…

In 1781 a group of merchants and ship owners petitioned Trinity House for navigation lights to be provided around the western approaches to the Solent. The response was positive, but it was not until 1785 that construction began, on three new lighthouses: one on the clifftop above the Needles, one on Hurst Point and one on St Catherine's Down (which was left unfinished and never lit); all three were designed by Richard Jupp. however, its height of 496 ft above sea level meant it was often obscured by fog and sea mists, a problem that eventually led to its replacement some 70 years later. Illumination was provided by 13 Argand lamps with parabolic reflectors; The light initially shone white,…

Today the main lamp is a 1500W bulb; the fixed optic with its coloured sectors remains in use as of 2019. Due to the condition of the chalk strata on which the lighthouse was built, in April 2010 a £500,000 underpinning project was announced, designed to stop the lighthouse falling into the sea. Over a 12-week period from early June, civil marine contractors Nuttall John Martin excavated a trench around the base of the lighthouse, to install a ring of stabilising posts, reinforced with concrete. Upgrade works took place in 2023, during which redundant equipment was removed; in May of that year the range of the light was reduced.
